Description
- Specifications and Features
– Java Card Version 3.0.5 Classic Edition.
– GlobalPlatform Version 2.3.
– Secure Channel Protocol (SCP): SCP 01, 02 (default) and 03.
– Delegated Management.
– Secure Box.
– Physical Unclonable Function (PUF).
- Available Memory and Technology
– FLASH (available before loading MIFARE, Applets, OS Addons): 180KB.
– CMOS Technology CMOS040.
- MIFARE IC
– MIFARE Classic / Plus Implementation EV1 – up to 4kB (optional).
– MIFARE DESFire Implementation EV2 – up to 8kB (optional).
- Transaction Performance
– SAC Electronic Passport < 2s.
– MasterCard Transaction Time < 200ms.
- Cryptography
– DES/TDES 56b, 112b and 168b.
– AES 256b.
– RSA 4096b.
– ECC GF(p) 521b.
– SHA 128b, 224b, 256b, 384b and 512b.
- Certifications and Approvals
– EMVCo Platform Approval.
– VISA Approvals.
– MasterCard PIC (TAS & CAST).
– EMVCo CPA.
– Common Criteria for OS: EAL 6+ (AVA_VAN.5, ALC_FLR.1 and ASE_TSS.2).
– Federal Information Processing Standard (FIPS): 140-2 level 3.
